Stainless Steel Tube Mill for Furniture Pipes Manufacturer

Stainless steel Tube Mill is design to produce welded round tubes,with diameter 4.8mm-325mm,thickness 0.2mm-6.0mm. The tube mill is newly design based on proactical producing and acquiring the advantages of equipment home and abroad, which is also convenient in operation and maintenance.


Phone/Whatsapp:

+86 18818745372

  • Description
  • Show
  • Parameters
  • Application
    • Commodity name: Stainless Steel Tube Mill for Furniture Pipes Manufacturer
    • Commodity ID: 1070428245280313344

    Stainless steel Tube Mill is design to produce welded round tubes,with diameter 4.8mm-325mm,thickness 0.2mm-6.0mm. The tube mill is newly design based on proactical producing and acquiring the advantages of equipment home and abroad, which is also convenient in operation and maintenance.

    Stainless Steel Tube Mill

    Stainless Steel Tube Mill for Furniture Pipes Manufacturer

    Stainless steel Tube Mill is design to produce welded round tubes,with diameter 4.8mm-325mm,thickness 0.2mm-6.0mm. The tube mill is newly design based on proactical producing and acquiring the advantages of equipment home and abroad, which is also convenient in operation and maintenance.

    steel tube mill

    Steel Tube Mill’s Line-Up Arrangement (Stainless Steel)

    stainless steel tube mill

    • Un-coiler

    • Strip guide + Strip leveler

    • Forming Section ( furniture: break down 3~4 + by-pass 3 + Fin pass 3~4 )

    • Welding Section (Squeezing Roll set 3) + anti-twister (Welder: Tig/Plasma+Tig/Tig+Plasma+Tig, according to required working thickness & speed)

    • Seam polisher 3~4 units

    • 1st sizing 2 (for decorative only one section 3~4 units required)

    • Turk-Head (1 unit for round, 2~3 units for square)

    • Flying Cutter

    • Pipes collector

    Application for SS Tubes - Stainless Steel Tube Mill for Furniture Pipes Manufacturer

    The finished steel tubes can be used for decorative area, such as furniture,handrail,window, door, and so on.

    stainless steel tube mill

    The advantages of Stainless Steel Tube Mill for Furniture Pipes Manufacturer:
    • Easy-operation.
    • Stable mechanical performance.
    • Accuracy in end product result.
    • Economic input energy (source).
    • Easy in maintenance,(usage targeting at 25 years).
    • Fast production speed with proper welding system.
    • Much affordable in initial investment.
    • Require minimized work force in operation.
    Key words:
    • stainless steel tube mills
    • steel tube mill
    • tube mill
  •
    Brand:
    YXH
    Product:
    Furniture stainless steel tube mills
    Colour:
    White/Green/Blue
    Voltage:
    220/380/415/440V
    Useful time:
    20 years
    Warranty Time:
    1 year

    After-Sales
    Service Provide:
    Offer advisable investing solution on stainless steel tube mills
    Colour:
    White/Green/BlueVoltage:220/380/415/440V

    Type
    Horizontal
    Shaft
    Dia(mm)
    Vertical
    Shaft
    Dia(mm)
    Material
    Pipe
    Diameter(mm)
    Pipe
    Thickness(mm)
    Capacity
    (m/min)
    Major Power
    (KW)
    Installation
    Size
    (L*W)(m)
    S-ZG40
    40
    25
    ss,cs,etc
    6-31.8
    0.2-1.0
    1-20m/min
    5.5KW
    20.0×1.0
    ZG40 40
    40
    25
    ss,cs,etc
    8-50.8
    0.2-1.5
    1-15m/min
    7.5KW
    21.5×1.1
    B-ZG40
    40
    25
    ss,cs,etc
    8-63.5
    0.3-2.0
    1-10m/min
    11KW
    21.5×1.1
    ZG50
    50
    30
    ss,cs,etc
    19.05-76.2
    0.4-2.5
    1-7m/min
    15KW
    24.0×1.2
    ZG60
    60
    40
    ss,cs,etc
    38.1-114
    0.5-3.0
    1-5m/min
    15KW
    26.0×1.4



  • tube mills

    Furniture Stainless Steel tube mills Advantage:
    • Easy-operation.
    • Stable mechanical performance.
    • Accuracy in end product result.
    • Economic input energy (source).
    • Easy in maintenance,(usage targeting at 25 years).
    • Fast production speed with proper welding system.
    • Much affordable in initial investment.
    • Require minimized work force in operation.
